Power supply8…35VDC
Power25mW…0.8W
Voltage drop8.0VDC
RTD input typePt100，Pt1000，Ni100，Ni1000
Cable resistance5Ω（Max）
Sensor current＞0.2mA，＜0.4mA
Influence of sensor cable resistance on
accuracy (3-line)＜0.002Ω/Ω
Sensor fault detectionYes
Minimum linear resistance...the biggest0…10000Ω
TC thermocouple modelB , E , J , K , L , N , R , S , T , U , W3 , LR
Cold junction compensation（CJC）＜±1.0℃
Sensor fault current: during measurement/otherNom. 33μA / 0 μA
Current output4…20mA
Minimum signal range16mA
Load（@cureent output）（Vsupply-8）/ 0.023Ω
Load stability0.01%F.S / 100Ω
Sensor fault alarm output3.5…23mA
Upper/lower current in accordance with
NAMUR NE43 standard23mA/3.5mA
Turnover time135ms
